J606J606 |
|
|
|
|
|
|
|
 |
J120 Ch
|
|
|
SPECIFICATIONS
|
|
MODEL:J606
(8POLE)
|
|
|
|
VOLTAGE
|
VAC
|
12,24,100,115,200,220,240
|
|
POWER FRNQUENCY
|
Hz
|
50/60
|
|
POWER INPUT
|
W
|
3
|
|
NO-LOAD
CURRENT
|
mA
|
35/30(110VAC)
|
|
RATED
SPEED(ROTOR)
|
r. p. m.
|
900/750
|
|
ROTATION
DIRECTION
|
CW,CCW
|
CW,CCW, Bi-direction
|
|
START TORQUE
(THEORETICAL
OUTPUT)
|
kg-cm
|
14 (1 r. p .m)
|
|
STALL TORQUE
(THEORTICAL
OUTPUT)
|
kg-cm
|
16(1 r. p. m)
|
|
TEMPERATURE
RISE
|
Deg.
|
55℃
|
|
AMBIENT
OPERATING TEMPERATURE
|
Deg.
|
-10~+50 ℃
|
|
INSULATION
DIELECTRIC STRENGTH
|
|
AC 1,500V- -1 min
|
|
WEIGHT
|
g
|
100
|
|
Output Shaft
Speed
|
r.p.m.
|
Optional
|
|
|
|
|
| |
|
