SPECIFICATIONS
|
|
MODEL
|
|
|
|
VOLTAGE
|
VAC
|
12,24,100,115,200,220,240
|
|
POWER
FRNQUENCY
|
Hz
|
50/60
|
|
POWER INPUT
|
W
|
6
|
|
NO-LOAD
CURRENT
|
mA
|
80 (110VAC)
|
|
RATED SPEED
(ROTOR)
|
r. p. m.
|
500/600
|
|
ROTATION
DIRECTION
|
CW,CCW
|
REVERSIBLE
|
|
START TORQUE
(THEORETICAL
OUTPUT)
|
kg-cm
|
110(1 r. p .m)
|
|
STALL TORQUE
(THEORETICAL
OUTPUT)
|
kg-cm
|
120(1 r. p. m)
|
|
TEMPERATURE
RISE
|
Deg.
|
65 ℃
|
|
AMBIENT
OPERATING TEMPERATURE
|
Deg.
|
-10~ + 50 ℃
|
|
INSULATION
DIELECTRIC STRENGTH
|
|
AC 1,500V- -1 min
|
|
WEIGHT
|
g
|
280
|
|
CAPACITOR
|
μF
|
4.7(24v), 0.68(110v),
0.15(220v)
|
|
PLASTIC GEAR TRAIN OUTPUT SPEED(rpm) & TORQUE(kg-cm) TABLE
|
|
50Hz
|
1/100
|
1/120
|
1/133
|
1/160
|
1/180
|
1/240
|
1/360
|
1/480
|
1/720
|
1/960
|
|
OUTPUT SPEED @60Hz
|
60
|
20
|
12
|
10
|
6
|
4
|
3
|
2.4
|
2
|
1.2
|
|
TORQUE
|
1.5
|
4.5
|
8
|
10
|
18
|
20
|
20
|
20
|
20
|
20
|
|
METAL GEAR TRAIN OUTPUT SPEED(rpm)& TORQUE(kg-cm) TABLE
|
|
REDUCTION RATIO
|
1/10
|
1/30
|
1/50
|
1/60
|
1/100
|
1/150
|
1/200
|
1/250
|
1/300
|
1/500
|
|
OUTPUT SPEED @60Hz
|
60
|
20
|
12
|
10
|
6
|
4
|
3
|
2.4
|
2
|
1.2
|
|
TORQUE
|
1.5
|
4.5
|
8
|
10
|
18
|
20
|
20
|
20
|
20
|
20
|
|
REDUCTION RATIO
|
1/700
|
|
|
|
|
|
|
|
|
|
|
OUTPUT SPEED @60Hz
|
0.86
|
|
|
|
|
|
|
|
|
|
|
TORQUE
|
20
|
|
|
|
|
|
|
|
|
|
FEATURE
LOW COST, PRECISION, COMPACT SIZE, HIGH
TORQUE, LOW NOISE
APPLICATION
AIR CONDITIONER, ELECTRIC FAN, MICROWAVE
OVEN, LAMINATOR, SPOTLIGHT…etc.
|
