SPECIFICATIONS
ITEM
DRIVE VOLTAGE ±10%
V DC
12
CURRENT PER PHASE
mA
600
RESISTANCE PER WINDING
Ω
20
No. of PHASE
－
4
EXCITATION MODE
Uni-polar Drive
POLE
24
STEP ANGLE
DEG
7.5°
HOLDING TORQUE
g.cm
2400
DETENT TORQUE
400
PULL-OUT TORQUE/100PPS
800
MAX.STARTING FREQUENCY
pps
230
MAX.RESPONSE FRENQUENCY
250
12V 100pps TEMPERATURE RISE
deg
70 °C
INSULATION RESISTANCE
MΩ
10M Ohm (DC 500V)
DIELECTRIC STRENGTH
500VAC FOR ONE MINUTE
AMBIENT TEMPERATURE
-5 ~ +50 °C
WEIGTH
gf
425
